Zigbee CC2540 Bluetooth 4.0 module
CC2540 is a low-power, highly integrated 2.4-GHz transceiver
that suitable for systems targeting compliance with worldwide radio-frequency.
It is designed based on TI(chipcon) CC2540 radio transciver IC. The application engineers can easily apply the RF module for its application without worrying about the specific impedance matching or soldeing fine pitch related radio designing issues.
Features:
- Power consumption: 18.2MA(MAX)
- Idle Mode: <1ua
- The Distance: 20 meter (1M Data Rate)
- VOLTAGE: 2.0-3.6V
- Antenna: External or PCB Antenna
- Package: Both SMD and DIP are support
– 2.4-GHz Bluetooth low energy Compliant and Proprietary RF System-on-Chip
– Supports 250-kbps, 500-kbps, 1-Mbps,2-Mbps Data Rates
– Programmable Output Power up to 0 dBm
– Excellent Receiver Sensitivity (–94 dBm at1 Mbps), Selectivity, and Blocking Performance
– Suitable for Systems Targeting Compliance With Worldwide Radio Frequency Regulations: ETSI EN 300 328 and EN 300 440 Class 2 (Europe), FCC CFR47 Part 15(US), and ARIB STD-T66 (Japan)
- Quality: Each module test 4 times before shipping it out. (Function test (2times), Frequency Calibration, Distant test)
Applications
> 2.4GHz low-power Bluetooth Energy Systems
>proprietary 2.4-GHz systems
>human-interface devices(keyboard, mouse, remote control) sports and leisure equipment
> Mobile phone peripherals
> Sports and fitness devices
> Consumer Health and Medical
> Home / Building Automation
> Consumer Electronics
Pin description:
